💡 What You Get

• Best Portable Pump for Viscous Fluids: Transfer 7 gallons per minute
• Pump from a Distance: Self-priming design for immediate pumping.  Suction lift is 15′ and push height is 90′.
• Industrial Durability: Built for professional daily use
• Long-Term Reliability: Motor is built to last.  Easy seal replacement and servicing.
• Professional Technical Assistance and Extended Warranty Option

---

⚙️ Detailed Specifications

Overall Specs

• Dimensions: 17″ × 11″ × 7″
• Weight: 35 lbs
• Temperature Rating: Up to 375 °F
• Flow Rate:  7 GPM
• Ports: .75″ NPT with hose barbs or cam-lock quick connects.
• Seals: Viton (B100 biodiesel compatible)
• Self-priming design with reversible flow

Pumphead Specs

• .75″ NPT Female Ports
• Close Coupled gears
• No bypass for heavy oils
• Stainless or Cast Iron
• 1 gasket and 1 viton seal(on shaft)
• 14mm shaft
• Includes oversized Lovejoy L075 spider couplings

Motor Specs

• Power: 1/2 HP, single-phase Motor
• Voltage: 115/230 V, 60 Hz (dual voltage ready)
• RPM: 1,725–1,800 RPM for steady torque under load
• Enclosure: TEFC (Totally Enclosed Fan Cooled), IP54 dust & water resistant
• Insulation: Class F, VPI impregnated windings for heat & moisture resistance
• Shaft & Bearings: 14 mm keyed shaft, double-sealed ball bearings, with improved drive-end seal
• Service Factor: 1.15, handles overloads with ease
• Starting: Capacitor start / induction run for strong startup torque
• Corrosion Resistance: Anti-rust rotor coating for extended lifespan
• Farm Duty 1/2HP industrial motor
• 6.5 amp draw
• Pre-wired with water resistant switch and 3-prong power cord
• Thermally protected with Manual Override

---

💲 Investment

• Heavy-duty 1 HP TEFC motor with Viton seals
• B100 biodiesel compatibility
• Reversible flow capability
• 1″ ports with stainless barbs
• Continuous duty rating
• Comprehensive warranty + professional tech support

ROI: Save 10–30 minutes per transfer. Across multiple jobs daily, that’s significant labor cost savings and increased throughput.

---

✅ Compatibility

Ideal for:

• Motor Oil
• Waste Motor Oil (WMO)
• Gear Oil
• Hydraulic Fluid

Not for:

• Water
• Highly aqueous solutions
• Highly flammable liquids

---

🔌 Power Requirements

• Standard 15 amp residential outlet
• Generator: 3,000 W continuous / 3,500 W peak
• 12 V Inverter: 5,000 W continuous / 6,000 W peak

---
